Puntos de enmascaramiento de alta temperatura

Puntos de enmascaramiento de alta temperatura

SKU: 301-017-04

Description

Puntos de enmascaramiento para revestimiento conformado de alta temperatura

Aplicaciones principales:

Recubrimiento conformado: capa protectora de material que se aplica a los componentes electrónicos y a las placas de circuitos. Ayuda a proteger los componentes de factores ambientales como la humedad, el polvo, los productos químicos y las fluctuaciones de temperatura, lo que mejora su durabilidad y fiabilidad.
Película base: Papel resistente a altas temperaturas.
Color: Amarillo
Adhesivo: Caucho
Espesor total: 180+/-5 micras
Resistencia al pelado: >0,28 KN/M
Tack inicial: >10# (prueba de pelota)
Poder de retención: > 15h
Temperatura: 160 grados C x 30 min

Paquete

Núcleo: Núcleo de papel normal / 3”
Longitud: 50m

Features

Specifically designed for conformal coating applications
Protects components from moisture, dust, chemicals, and temperature changes
Base film made from high-temperature resistant paper
Yellow colour for easy visibility
Rubber adhesive ensures strong adhesion and clean removal
Total thickness of 180 +/- 5 microns
Peel strength greater than 0.28 kN/m for secure attachment
Initial tack >10# (ball test) for quick application
Holding power of over 15 hours
Can withstand temperatures up to 160°C for 30 minutes
Package: Supplied on a 50m roll with a plain paper core (3” diameter)
All sizes have 2,000 units per reel, with the exception of the 11mm and 21mm variants, which have 1,000 units per reel.

DOWNLOAD DATASHEETS

1. Technical Data Sheet

BUY 10+\u003e5 SAVE 10+\u003e5%

Stock	Tamaño	SKU	1-9	10+\u003e5	Total
17	4 mm	301-017-04	£20.88 Ex. VAT	£20.88 Ex. VAT	£0.00 Ex. VAT
0	6 mm	301-017-06	£30.19 Ex. VAT	£30.19 Ex. VAT	£0.00 Ex. VAT
1	7 mm	301-017-07	£35.66 Ex. VAT	£35.66 Ex. VAT	£0.00 Ex. VAT
5	8 mm	301-017-08	£40.25 Ex. VAT	£40.25 Ex. VAT	£0.00 Ex. VAT
1	9 mm	301-017-09	£43.23 Ex. VAT	£43.23 Ex. VAT	£0.00 Ex. VAT
0	10 mm	301-017-10	£43.71 Ex. VAT	£43.71 Ex. VAT	£0.00 Ex. VAT
5	11mm / 1000pcs	301-017-11	£21.97 Ex. VAT	£21.97 Ex. VAT	£0.00 Ex. VAT
0	21mm / 1000pcs	301-017-21	£45.21 Ex. VAT	£45.21 Ex. VAT	£0.00 Ex. VAT

If stock level is 0 or not shown, you can still ORDER ONLINE and we will advise you by email when your back-ordered item/s will be delivered.
